Cutting Plasma Plotter Hi Definition

Cutting Plasma Plotter Hi Definition

  •  Cutting Plasma Plotter operated by CNC 100 with 2 axis with linear and circular interpolation
  • Brushless ABB drivers and motors 750 W ;
  • Steel power loom externally varnished ;
  • Head device for use with marker
  • Working area mm 4000 x 1500 mm ;
  • Software BRAVO V.2.9 provided with rectangular and circular pieces, for insulation and chimneys stack .
  • Import/Export drawings by an external CAD ;
  • Plasma generator CEBORA High definition Model PROF 164 ;
  • Panel Pc with o.s. Windows Xpe.USB for load program by USB pen drive;
  • Working with thickness from 1 up to 20 mm
  • Automatic control height torch .
    ··
    “Bravo” software with a library consisting of more than 120 articles parameterizable
    · for se sectors of conditioning,,ventilation,insulation,flue,carpentry.
    · Using the software on the machine also.
    – Dimensions : L 4800 mm – W 2200 mm – H 1200 mm;
    – Weight Kg. 2.000.
    – Electrical connection: 380 Volt – 50 Hz 10 A for electric cabinet
    63 A for plasma source
    The machine needs an aspirator with filter with a capacity of
    4000 m3 hours
    Accessories.
    Aspirator with filter 3000 mc/h
    In order to improve the product Eurosoft reserves the right to make changes without notice.
