Cutting Plasma Plotter

Cutting Plasma Plotter

• Cutting Plasma Plotter operated by CNC 100 with 2 axis with linear and circular interpolation
• Brushless ABB drivers and motors 750 W ;
• Steel power loom externally varnished ;
• Head device for use with marker
• Working area mm 3200 x 1500 mm ;
• Software BRAVO V.2.9 provided with rectangular and circular pieces, for insulation and chimneys stack.
• Import/Export drawings by an external CAD ;
• Plasma generator CEBORA powered by 60 A mod. 6060/T or Thermal A40 ;
• Panel Pc with o.s. Windows Xpe.USB for load program by USB pen drive
• Working with thickness from 0.5 to 5 mm


– Dimensions : L 4000 mm – W 2200 mm – H 1200 mm;
– Weight Kg. 1.800.
– Electrical connection:

380 Volt – 50 Hz

10 A for electric cabinet
20 A for plasma source

The machine needs an aspirator with filter with a capacity of 3000 m3 hours

Accessories.
Aspirator with filter 3000 mc/h
In order to improve the product Eurosoft reserves the right to make changes without notice.
